Home /Products/Mixing Tank/Pneumatic Lifting High Shear Disperser Mixer Paint Ink Cosmetic Homogenizer

Pneumatic Lifting High Shear Disperser Mixer Paint Ink Cosmetic Homogenizer

1
MOQ
$1,000-1,500
Price
Pneumatic Lifting High Shear Disperser Mixer Paint Ink Cosmetic Homogenizer
Features Gallery Product Description Chat Now
Features
Specifications
Mixer Type: Agitator
Material Processed: Chemicals, Food, Cosmetic
Range Of Spindle Speed(r.p.m): 1 - 63
Weight (kg): 500
Material: SUS304, SUS316L
Product Type: Cosmetic
Motor Type: DC Motor
Additional Capabilities: Milling
Voltage: 220V/380V
Dimension(l*w*h): Referring
Power (kW): 3 KW, 4 KW, 5 KW
Warranty: 1 Year
Key Selling Points: High Productivity
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Core Components: Motor
Capacity: 200 L, 100 L, 50 L
Product Name: 100 Litre Stainless Steel Mixing Pot Mixer Equipment
Keyword: Liquid Detergent Shampoo Mixing Machine
Material Processed: Chemicals, Food
Barrel Volume: 50L-5000L Customized
Heating Methord: Steam Or Electricity
Application: Liquid Soap, Hand Sanitizer, Shampoo, Detergent
Homogenizer: Bottom Homogenizer
Mixing Type: Wall Scraper Mixer
Stirrer Type: Paddling Stirring
Motor: Explosion-proof Motor, ABB
Highlight:

Pneumatic Lifting High Shear Disperser

,

Paint Ink Cosmetic Homogenizer

,

200L Dispersing Mixer
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Cosmati
Payment & Shipping Terms
Packaging Details: wooden cases
Delivery Time: 7 work days
Payment Terms: TT
Supply Ability: 10000 set
Product Description
CE Pneumatic Lifting Barrel Disperser Paint Mixer Ink Dye Mixing Equipment High Shear Homogenizer

Usage

It makes full use of the high-speed rotation of the homogenizing head connected to the engine to make the material blend with oil and water and become more delicate. The material is continuously ejected from the radial direction at high speed, and the flow direction is changed under the resistance of the material itself and the container wall. At the same time, under the effect of the upper and lower axial suction forces generated in the rotor area, two strong turbulent turbulent flows are formed. The material passes through several cycles, and finally completes the process of dispersion, emulsification and homogenization.

Features

  1. It is efficient equipment for low-speed mixing, high-speed dispersion, dissolution and mixing of liquids and solids powders with different viscosities.
  2. Pneumatic lifting, simple operation, flexible movement, low noise and stable operation.
  3. The mixer adopts a motor with the power of 5.5kW, variable frequency speed regulation, rotating speed of 0-1440 rpm, and the support is made of stainless steel SUS304.
Capacity
50-500L(Customized)
Contacted part
SS316L
Frame material
SUS304
Electrical Appliances
DELIXI, China
Speed
0-3000rpm
Motor
, Germany
Power
5.5KW
Inverter
Delta, Taiwan
Size(L*W*H)
1000*1000*2100mm
Type
Pneumatic lifting

Factory profile
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 0
Engineer case
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 1
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 2
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 3
Trade show participation
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 4
Packaging & shipping specifications
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 5

Application
Pneumatic Lifting High Shear Disperser Mixer Paint Ink Cosmetic Homogenizer

FAQ

1. What products can this high shear disperser process?

The machine is suitable for paint, ink, dye, pigment, coating, liquid detergent, shampoo, hand sanitizer, liquid soap and other chemical or cosmetic liquid materials.

2. What is the main function of this machine?

The machine provides high speed dispersing, mixing and homogenizing to help break down agglomerates and distribute powders, pigments or other ingredients more evenly throughout the liquid.

3. Is this machine supplied with a mixing tank?

The shown equipment is mainly a lifting disperser unit. A stainless steel mixing tank can be supplied separately and customized according to the required batch capacity.

4. What tank capacities can be matched?

Common configurations include 50L, 100L and 200L tanks.

According to the supplied information, customized tank capacities from approximately 50L to 5000L can also be discussed.

5. How does the lifting system work?

The machine uses a lifting structure that raises and lowers the dispersing shaft, allowing the mixing head to enter or leave the processing tank conveniently.

This makes tank replacement, material loading and cleaning easier.
