Home /Products/Perfume Filling Machine/10 Heads Filling Machine for Perfume Liquid Negative Pressure Stainless Steel 316L

10 Heads Filling Machine for Perfume Liquid Negative Pressure Stainless Steel 316L

1 SET
MOQ
1000-100000 USD
Price
10 Heads Filling Machine for Perfume Liquid Negative Pressure Stainless Steel 316L
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: 10 Heads Top Quality Filling Machine For Perfume/liquid
Keywords: Perfume Filling Machine
Dimension: L900xW500XH1300mm
Machinery Capacity: 4000BPH, 20000BPH, Other
Filling Accuracy: ±1%
Production Capacity: 10-30 Bottles/min
Noise: 70dB(A)
Material: Stainless Steel 304/316
Key Selling Points: High-accuracy
Filling Nozzels: 10pcs
Filling Volume: 5-1000ml
Usage: Filling Perfume
Highlight:

10 Heads Perfume Filling Machine

,

Negative Pressure Filling Machine

,

316L Stainless Steel Filling Machine
Basic Infomation
Place of Origin: GUANGZHOU,CHINA
Brand Name: COSMATI
Certification: CE
Model Number: CM-PFM
Payment & Shipping Terms
Packaging Details: wooden cases
Delivery Time: 7 work days
Payment Terms: TT
Supply Ability: 10000 set
Product Description

10 heads top quality filling machine for perfume/liquid

10 Heads Filling Machine for Perfume Liquid Negative Pressure Stainless Steel 316L

Introduction:

*Negative pressure suction liquid filling, the product filling volume is measured by the height of the liquid level
* Equipped with casters, easy to move
*Stainless steel 316L is used in contact with materials, and stainless steel 304 is used for the tabletop
*Suitable for glass bottles, or plastic bottles whose body is not easily deformed after being evacuated, convenient for adjustment, operation and maintenance
*Ideal equipment for liquid level filling such as toilet water, perfume, toner and other liquid materials


Technical Parameter:

Production Capacity20-40 bottles/min
Filling Volume5-1000ml
Suitable bottle height≤250mm
Suitable bottle diameter≤90mm
Application of Bottle Diameter≥5mm
Supply Voltage3/N AC 380V/220V


Power Consumption

0.55KW 0.75KW

( explosion proof Noise 70dB(A)


Factory profile
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 0
Engineer case
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 1
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 2
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 3
Trade show participation
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 4
Packaging & shipping specifications
Cosmetics Chemical Liquid Soap Making Machine Mixing Equipment Hydraulic System 5

FAQ

1. What products can this 10-head filling machine handle?
This machine is mainly designed for perfume, fragrance, cologne, toner, facial mist and other low-viscosity liquid products.

2. How many filling nozzles does the machine have?
The supplied configuration uses 10 filling nozzles, allowing multiple bottles to be filled during each production cycle.

3. What is the filling volume range?
According to the supplied specification, the filling range is approximately 5–1000 ml, depending on the bottle size and machine setup.

4. What is the production speed?
The listed production capacity is approximately 10–30 bottles per minute, depending on filling volume, bottle size and operating conditions.

5. What is the filling accuracy?
The supplied specification lists approximately ±1% filling accuracy, depending on liquid characteristics and filling volume.
