Automatic aerosol spray filling machine machine filling spray cans

Minimum Order Quantity : 1 set Price : $2000-5000/set
Packaging Details : Wooden case Delivery Time : 5-7 days
Payment Terms : L/C, T/T Supply Ability : 20 sets
Place of Origin: Guangdong,China Brand Name: Cosmati
Certification: CE Model Number: CM-QWJ-B

Detail Information

Product Name: Automatic Aerosol Spray Filling Machine Machine Filling Spray Cans Keyword: Aerosol Cans Filling Machine
Automatic Grade: Semi-automatic Key Selling Points: High Productivity
Application: Chemical, Pharmaceutical,Medical Packing: Wood Case
Usage: Aerosol Spray Filling Voltage: 220V
Working Pressure: 0.5-0.7 MPa

Product Description

Professional security automatic aerosol spray filling machine machine filling spray cans

Product Description

_

0090



Details:

Automatic aerosol spray filling machine machine filling spray cans 2Automatic aerosol spray filling machine machine filling spray cans 3

Introduction:

Product number: CM-QWJ-B

Product Name: Three-in-one Aerosol Filler

Product Series: Aerosol Series

Operation mode: automation



Product advantages:

1. Fast speed, high accuracy, good stability, time and effort saving

2. All actions can be completed at the same time by only one person operating the pedal valve once.



Technical parameters:

Model CM-AFM-01
Sealing diameter(mm) Ф26.5-Ф27.5
Sealing depth(mm) 5.0-6.0
Applicable valve 1”
Applicable aerosol cans Height(mm) 80-315mm
  Diameter(mm) 35-70mm
Maximum liquid filling volume 450ml
Liquid refilling accuracy ≤±1.0%
Maximum filling volume of propellant 450ml
Propellant repeat filling accuracy ≤±1.0%
Working pressure (MPa) 0.50-0.70MPa
Maximum air consumption 0.6m3/min
Production capacity 800-1200 cans/hour
Dimensions (mm) 1000×600×1600
Weight (kg) 240



Product characteristics:

1. The machine is integrated from the original semi-automatic aerosol filling machine through improvement, optimization and integration.

2. Install three semi-automatic filling, sealing and filling machines on one workbench.

3. All actions can be accomplished simultaneously by one person at a time operating the pedal valve.

4.Fast speed, high accuracy, good stability and time-saving are ideal choices for small and medium-sized aerosol manufacturers.

5. Suitable for filling various media, such as thin liquid (kerosene), viscous liquid (face wash, polyurethane foaming agent).







OUR MAIN PRODUCTS:



6747

5363




Mixing equipment Vacuum homogenization emulsifier Labeling machine
Inquiry Now Inquiry Now Inquiry Now





Automatic aerosol spray filling machine machine filling spray cans 7







0013

003
Liquid paste filling machine Digital small liquid filling machine Aerosol filling machine
Inquiry Now Inquiry Now Inquiry Now
10   10 10 .png
Perfume filling machine Cosmetic powder press machine Grinding machine
Inquiry Now Inquiry Now Inquiry Now



Application






Company Information

00001 Factory750

Automatic aerosol spray filling machine machine filling spray cans 18LOGO

Our Main Markets:


FAQ



Q: How to order?

A: We are available via email, please feel free to send us your requests. It will be nice if you can tell us details of your products, such as product name, product picture, valve size, can height&diameter, etc. If needed, turnkey solution will be provided to you.

Q: Can I visit your factory?

A: Welcome to visit our factory. Our factory is in Guangzhou City, Guangdong Province. There is an international airport near here. Therefore, it is very convenient for worldwide customers to visit our factory.

Q: What's your regular packing?

A: Products are usually packed in plastic bag - pallet - wooden case. Customized packing is available.

Q: What about after sale service?

A:Engineer will go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines.When machine has problem, We will solve basic questions by telephone, email, whatsapp, wechat and video call.

Customers showing us the picture or video of the problem. If the problem can be easily solved , we will send you solution by video or pictures. If the problem out of your control, we will arrange engineer to your factory.

Q:How can you control the quality and delivery?

A:All our machines will be tested before packaging. Teaching video and packing pictures will be sent to you for checking,we promise that our wooden packaging is strong enough and safety for long delivery .

Q:How about warranty and spare parts?

A:We provide 1 year warranty and enough spare parts for the machine,and most of the parts can be found in local market also,also you can buy from us if all the parts that over than 1 year warranty.
